Sachtler 萨科勒 1018AM 中置脚架云台套装 沙雀 System Ace XL AL MS MKII 1018A升级 三脚架液压云台套装
¥ 13100.00元
相关推荐
System Ace XL AL MS Mk II
SKU: 1018AM
- Ace XL system with 2-stage aluminium tripod
- Supports payloads up to 8kg (17.6lbs)
- Nine steps of counterbalance
- Sachtler drag with 3 + 0 steps
- Illuminated level bubble
- Accessory mounts on tripod bowl
- Ace bag, mid-level spreader, and carry handle included
Are you ready?
With Ace, precision meets dedication. Achieve finesse in every shot with fast counterbalance, and smooth drag adjustments. Lightweight and compact, with consistent performance, Ace is along for the journey. From urban jungles to the call of the wild, be ready for every opportunity that comes your way.
With Ace in your corner, stability and smoothness comes with every shot. It simplifies your setup with camera plate markers, stepped counterbalance and quick pan and tilt adjustments. Ace XL supports camera rigs weighing up to 8kg (17.6lbs), with nine steps of balance to quickly match your payload. A 104mm (4.1in) balance plate sliding range helps position accessorised cameras centrally and Sachtler drag gives smooth movement in any temperature. Ace XL also includes an illuminated level bubble to keep things straight in any location and detachable threaded stud for when you want to swap to a slider. Weighing just 4.4kg (9.7lbs), this Ace XL system is light in weight but not in features, so go further, climb higher and capture that winning shot unplanned or in the heat of the moment.
The System Ace XL AL MS includes a lightweight 2-stage aluminium 75mm tripod that’s portable without sacrificing strength. With three 3/8” accessory mounting points on the tripod bowl you can add something extra to your rig like a Magic Arm. Or attach the carry handle so you’re always ready to chase down the shot. The detachable flowtech-style mid-level spreader provides stability no matter how rocky the road. And when the road is long, Ace comes with a carry case for protection on the go.
Ace is built to earn its place on your journey. Designed with precision-engineered drag segments and rigorously tested materials, consistent performance is a given. That’s why Sachtler is trusted by professionals like you. Whatever path you choose to travel, Ace is your support system.
Technical Specifications
Metric Imperial
| Payload | 0 kg to 8 kg |
| Drag | 3 + 0 drag settings |
| Counterbalance | 9 + 0 |
| Bowl Size | 75 mm with integrated flat base |
| Height | 78 cm to 169 cm |
| Material | Aluminium |
| Tripod Stages | 2 |
| Spreader Type | Mid-level spreader |
| Weight | 4.4 kg |
| Transport Length | 86 cm |
| Pan Bar Count | 1 |
| Tilt Range | 90° to -75° |
| Sliding Range | 10.4 cm |
| Temperature Range | -30°C to 60°C |
| Pan Bar Type | Pan bar Ace |
| Level Bubble | Yes, illuminated |
| Camera Plate | Slide in |
| Fluid Head | Ace XL |
In The Box
Ace XL Mk II fluid head, tripod 75/2 AL MK II, mid-level spreader flowtech75 , rubber feet 75, bag Ace & carry handle
- S2170-0001 - Ace XL Mk II
- S2172-0001 - Tripod 75/2 AL Mk II
- S2082-1000 - Mid-level spreader flowtech®75
- SSP12P0150 - Rubber Feet 75
- 9117 - Ace bag
- S2051-1063 - Carry handle
系统王牌 XL AL MS Mk II
SKU: 1018AM
- Ace XL 系统配备两段式铝合金三脚架
- 支持较大 8 千克(17.6 磅)的有效载荷
- 平衡的九个步骤
- 萨赫勒拖动,3 + 0 步
- 发光水平气泡
- 附件安装在三脚架碗上
- 包括王牌袋、中层吊具和提手
准备好了吗?
有了 Ace,精准与专注并存。 通过快速平衡和流畅的阻力调节,实现每次射击的精巧性。 Ace 重量轻、结构紧凑、性能稳定,是旅途中的好帮手。 从城市丛林到野外的呼唤,准备好迎接每一个来临的机会。
有了 Ace 的帮助,每次击球都会更加稳定和顺畅。 它通过相机板标记、阶梯式平衡以及快速摇摄和俯仰调节,简化了设置过程。 Ace XL 支持重达 8 千克(17.6 磅)的摄像机支架,具有九级平衡,可快速匹配有效载荷。 104 毫米(4.1 英寸)的平衡板滑动范围有助于将配件相机置于中心位置,Sachtler 阻力可在任何温度下实现平稳移动。 Ace XL 还包括一个发光的水平气泡,可在任何位置保持水平,以及可拆卸的螺纹螺柱,方便您更换滑块。 这款 Ace XL 系统仅重 4.4 千克(9.7 磅),重量虽轻,功能却不弱,因此可以走得更远,爬得更高,在计划之外或紧急时刻捕捉到精彩镜头。
System Ace XL AL MS 包括一个轻便的 2 段式铝合金 75 毫米三脚架,既便携又不失强度。 三脚架碗上有三个 3/8 英寸附件安装点,您可以为您的装备添加额外的东西,比如魔术臂。 或者安装上提手,这样您就可以随时追赶射击目标了。 可拆卸的流线型中层吊具无论路面多么坎坷,都能提供稳定性。 如果路途遥远,Ace 还配有便携箱,可在旅途中提供保护。
Ace 是为在您的旅途中赢得一席之地而打造的。 采用精密设计的阻力段和经过严格测试的材料,性能始终如一。 这就是 Sachtler 深受您这样的专业人士信赖的原因。 无论你选择走哪条路,Ace 都是你的支持系统。
技术规格
公制
| 三脚架平台 | 2 |
| 倾斜范围 | 90° to -75° |
| 平移杆类型 | Pan bar Ace |
| 平移条数 | 1 |
| 抗衡 | 9 + 0 |
| 拖 | 3 + 0 drag settings |
| 有� | 0 kg to 8 kg |
| 材料 | 铝 |
| 水平气泡 | Yes, illuminated |
| 温度范围� | -30°C to 60°C |
| 滑动范围 | 10.4 cm |
| 相机板 | Slide in |
| 碗尺寸 | 75 mm with integrated flat base |
| 运输长度 | 86 cm |
| 重量 | 4.4 kg |
| 高度 | 78 cm to 169 cm |
包装盒内
Ace XL Mk II 液压云台、三脚架 75/2 AL MK II、中置伸展器 Flowtech75、橡胶脚垫 75、Ace 背包和提手
